SYBR 28680/22 Tapered Roller Bearings wanted-Choose Tapered Roller Bearings Manufacturer

SYBR 28680/22 Tapered Roller Bearings

Our company can provide specific bearing parameter, drawings, one-to-one solutions, and considerate after sales service. For more product information, please consult us at any time .We provide 24-hour service and await your calls respectfully!

Description

Technical

Application

Pictures

SYBR Tapered Roller Bearings:

Brand	SYBR or OEM
Name	inch taper roller bearing 28680 28680/22 28680/28622
Model	11710,11749 Series
	28680/28622,28985/28921,Series
	30306,30307,30303D Series
Material	Chrome Steel	Certificate	ISO9001:2001
Precision	P0, P6, P5, P4
Bore Size:	55.562mm	Outside diameter	97.630 mm
Clearance	C0,C1,C2,C3,C4,C5 etc.
Cage Type	Brass cage or Stainless cage
Seals Type	ZZ,RS, 2RS, R2, Z, 2Z, 2RZ etc
Features	The tapered roller bearing is mainly used to carry the radially and axially combined load, mostly the radial load.
Main beairng	deep groove ball bearings, spherical roller bearings, Angular contact ball bearing, pillow block bearing,ceramic Bearing, wheel bearing, cylindrical roller bearing, Insulating bearing, taper roller bearing
Application	The structure and assembly size and rotation precision taper roller bearing is different from the metric bearings. For the import of machinery or special needs of the industry
Package	pallet, wooden case,industrial package or as customers' requirement
MOQ	1PCS	PORT	Shen zhen,Shanghai,qingdao or according to your requirements
Price	FOB, CFR, CIF(please contact us)	Delivery Time	3-7 days

Shipping and Delivery:

Bearings Package:

Original Package:

1):Inner Plastic Bag+ Paper Box + Carton(+Pallet);

2):Small sizes:Plastic Tube + Carton

3):Big sizes:Wooden Case

Bearings Lead time:

We will prepare your order as soon as possible.

1)2-3 days for ex-stock

2)6-10 days for others

Shipping & Delivery time:

1)Less than 45 Kg:DHL TNT Fedex UPS express will be better,( 4-7 days delivered to your address);

2) Between 45 to 200 Kg:Air transiportation will be better,( 5-14 days delivered to your airport);

3) Over 200 Kg:Sea transportation will be better.( Cheapest,18-45 days to your port ).

Note:We will offer the best freight for you to save the shipping cost.Besides we provide all needed documents for your Customs clearance.Of course,your forwarder will be also welcome!

Inch Tapered Roller Bearing SET series Our Hotsale Products:

Model	Include	Model	Include
SET1	LM11749/LM11710	SET240	JW5049/JW5010
SET2	LM11949/LM11910	SET241	6386/6320
SET3	M12649/M12610	SET242	M88043/M88010
SET4	L44649/L44610	SET244	JF7049A/JF7010
SET5	LM48548/LM48510	SET245	JP10049/JP10010
SET6	LM67048/LM67010	SET247	JP12049/JP12010
SET7	M201047/M201011	SET249	14125A/14174
SET8	L45449/L45410	SET250	14138A/14274
SET9	U298/U261L+R	SET251	15103S/15243
SET10	U399/U360L+R	SET253	18590/18520
SET11	JL69349/JL69310	SET254	25577/25523
SET12	LM12749/LM12710	SET255	25581/25520
SET13	L68149/L68110	SET256	25583/25519
SET14	L44643/L44610	SET257	25584/25547RB
SET15	LM45449/LM45410	SET258	25590/25522
SET16	LM12749/LM12711	SET260	25877/25821
SET17	L68149/L68111	SET261	26882/26820
SET18	JL69349/JL69310	SET262	27687/27620
SET19	07100/07196	SET263	28580/28521
SET20	U399A/U365L+R	SET264	28580A/28527RB
SET21	1988/1922	SET265	29585/29522
SET22	LM67045/LM67010-Z	SET266	29590/29522
SET23	LM104949E/LM104911(EA)	SET267	29685/29620
SET24	JL68145/JL68111Z	SET268	LM29749/LM29711
SET25	JLM506848E/JLM506810	SET269	33281/33462
SET26	JLM104946/JLM104910-Z	SET270	33885/33822
SET27	JLM67048/LM67010-BCE	SET271	33889/33822
SET28	J15585/J15520	SET272	33895/33822
SET29	LM67049/LM67010	SET273	34301/34500
SET30	LM67042/LM67010	SET274	36690/36620
SET31	JL68145/JL68111	SET275	37425/37625
SET32	LM12748F/LM12710	SET276	39580/39520
SET33	JRM3534-90U01	SET277	39580/39528
SET34	LM12748F/LM12710	SET278	39581/39520
SET35	JRM3534/3564XD	SET279	39585/39520
SET36	LM603049/LM603012	SET280	U298/U261L(K529698)
SET37	JRM3939-90U08	SET281	42381/42584
SET38	LM104949/LM104911	SET282	42688/42620
SET39	JRM3939/68XD	SET283	45285A/45220
SET40	JLM506849A/JLM506811	SET284	U298/U261L(K525376)
SET42	JLM506849/LM506811	SET285	47487/47420A
SET43	15123/15245	SET286	48190/48120
SET44	L44643X/44610(O-ring&seal)	SET287	48286/48220
SET45	LM501349/LM501310	SET288	48385/48320
SET46	JL26749F/JL26710	SET289	52400/52618
SET47	LM102949/LM102910	SET290	53178/53377
SET48	JRM4042/76XDA (seal)	SET291	55187C/55437
SET49	LM12749FP/LM12710P	SET292	55187C/55443
SET50	02872/02820	SET294	55206C/55437
SET51	15106/15245	SET295	59162/59412
SET52	25580/25520	SET296	59175/59412
SET53	25580/25523	SET297	65225/65500
SET54	25590/25520	SET298	65237/65500-B
SET55	25590/25523	SET299	66200/66462
SET56	LM29748/LM29710	SET300	67391/67322
SET57	31594/31520	SET301	67883/67820
SET58	LM48548A/LM48510	SET302	68462/68712
SET59	LM48548A/LM48511A	SET303	15123/15245
SET60	LM48548/LM48511A	SET304	72212C/72487
SET61	11590/11520	SET305	77376/77675
SET62	17887/17831	SET306	78225/78551
SET63	M88048/M88010	SET307	09074/09194
SET64	HM903249/HM903210	SET308	M84548/M84510
SET65	M86647/M86610	SET309	M86649/M86610
SET66	368S/362	SET310	M88047/M88010
SET67	HM88649/HM88610	SET311	HM89443/HM89410
SET68	497/493	SET312	HM89449/HM89410
SET69	LM501349/LM501314	SET315	JM205149/JM205110
SET70	LM29749/LM29710	SET316	JM207049/JM207010A
SET71	LM67049A/LM67010	SET317	HM220149/HM220110
SET73	15101/15245	SET318	LM300849/LM300811
SET74	387A/382A	SET319	LM3503349A/LM503310
SET75	387A/382S	SET320	JLM508748/JLM508710
SET76	387AS/382A	SET321	HM516449C/HM516410
SET77	388A/382	SET322	495AX/493
SET78	55200C/55437	SET323	JHM522649/JHM522610
SET79	56425/56650	SET324	JLM714149/JLM714110
SET80	U497/U460L+R	SET325	JM714249/JM714210
SET81	HM88542/HM88510	SET327	JM720249/JM720210
SET82	JLM104949/JLM104910	SET328	M802048/M802011
SET83	HM803149/HM803110	SET329	HM803145/HM803110
SET84	HM807040/HM807010	SET330	HM803146/HM803110
SET85	25880/25820	SET331	HM804846/HM804810
SET86	399A/394A (seal)	SET332	HM807046/HM807010
SET87	07100/07196	SET333	JLM813049/JLM813010
SET88	LM11949/LM11910 (seal)	SET334	HM813841/HM813810
SET89	M12649/M12610 (seal)	SET335	HM813842/HM813810
SET90	13658/13621(seal)	SET336	JL819349/819310
SET91	LM29748/LM29710(seal)	SET337	M903345/M903310
SET92	L44643/L44610(seal)	SET339	HM911245/HM911210
SET93	LM48548/LM48510(seal)	SET340	H913842/H913810
SET94	LM67048/LM67010(seal)	SET341	H913842/H913810
SET95	2580/2523	SET342	JLM710949C/JLM710910
SET98	3984/3920	SET343	27695/27620
SET101	4A/6	SET345	350/354A
SET102	3585/3525	SET347	LM102949/LM102911
SET103	3982/3920	SET350	2796/2720
SET104	L44642/L44610+R	SET351	3579/3525
SET105	33287/33462	SET354	15103S/15245
SET106	LM78349/LM78310A	SET355	15579X/15520
SET107	JLM104948/JLM104910	SET356	23690/23620
SET108	JLM807045/JLM807012	SET357	28584/28521
SET109	683/672	SET358	65385/65320
SET110	6379/6320	SET359	78215C/78551
SET111	48290/48220	SET360	LM78349A/LM78310C
SET112	47896/47820	SET361	JM716649/JM716610
SET113	HM215249/HM215210	SET362	02474/02420
SET115	JH415647/JH415610	SET363	55175C/55437
SET116	74550A/74850	SET364	37431A/37625
SET117	64450/64700	SET365	395A/394A
SET118	JLM506849/JLM506810	SET367	72212AC/72487
SET119	H919942H/H919911	SET401	580/572
SET120	17580/17520	SET402	582/572
SET121	18790/18720	SET403	594A/592A
SET122	25580/25522	SET404	598A/592A
SET123	3780/3720	SET405	663/653
SET124	6580/6535	SET406	3782/3720
SET200	LM451349/LM451310	SET407	28682/28622
SET201	368A/362A	SET408	39590/39520
SET202	LM545849/LM545810	SET409	45280/45220
SET203	475/472A	SET410	45284/45220
SET204	570/563	SET411	47686/47620
SET205	469/453X	SET412	HM212047/HM212011
SET206	482/472	SET413	HM212049/HM212011
SET207	495A/493	SET414	HM218248/HM218210
SET208	497/492A	SET415	HM518445/HM518410
SET209	498/492A	SET416	45291/45220
SET210	527/522	SET417	47890/47820
SET211	528/522	SET418	H715334/H715311
SET212	537/532X	SET419	H715343/H715311
SET213	539/532A	SET420	H715345/H715311
SET214	559/552A	SET421	HM516449A/HM516410
SET215	575/572X	SET422	HM516449C/HM516410
SET216	594/592A	SET423	6461A/6420
SET217	598A/593X	SET424	555-S/552A
SET218	641/632	SET425	567/563
SET219	M88046/M88010	SET426	47679/47620
SET220	681/672	SET427	NP899357/NP026773
SET222	HM88649/HM88610	SET428	NP874005/NP435398
SET223	750A/742	SET429	NP034946/NP363298
SET224	855/854	SET430	NP840302/NP053874
SET225	861/854	SET431	NP965350/NP503727
SET226	1380/1328	SET432	NP174964/NP593561
SET228	2689/2631	SET433	NP431952/NP378092
SET229	2780/2720	SET434	NP555065/NP720703
SET230	2788/2720	SET435	NP568900/NP107783
SET231	2789/2720	SET436	NP577914/NP975161
SET232	835/832	SET437	NP022333/NP250023
SET233	3381/3320	SET438	NP417549/NP156827
SET234	3382/3320	SET439	HM212049X/HM212011
SET235	3478/3420	SET440	NP454049/NP454011
SET236	L305649/L305610	SET502	29675/29630
SET237	3975/3920	SET506	72225C/72487
SET238	JF4049/JF4010	SET509	HM516448/HM516414-B
SET239	A4050/A4138	SET511	H715345/H715313W
		SET512	47687/47623

Inch SYBR Tapered Roller Bearing Dimensions:

Modle	D(mm)	d(mm)	B(mm)
12168 12303	76.992	42.862	17.145
26884R 26822	79.375	42.875	25.4
25577 25520	82.931	42.875	25.4
L102849 L102810	73.025	44.45	18.258
12175 12303	76.992	44.45	17.145
18685 18620	79.375	44.45	17.462
25582 25520	82.931	44.45	25.4
3578R 3520	84.138	44.45	30.886
355 354A	85	44.45	21.692
355A 354A	85	44.45	21.692
HM803149 HM803110	88.9	44.45	29.37
49175 49368	93.662	44.45	31.75
46175 46368	93.662	44.45	31.75
46176 46368	93.662	44.45	31.75
33885 33821	95.25	44.45	28.575
438 432A	95.25	44.45	29.901
HM804842 HM804810	95.25	44.45	29.37
HM804843 HM804810	95.25	44.45	29.37
49576 49520	98.425	44.45	31.75
527 522	101.6	44.45	36.068
HM807040 HM807010	104.775	44.45	36.512
535 532A	111.125	44.45	36.957
615 612	120.65	44.45	41.275
3776 3720	93.264	44.983	30.302
358 354A	85	45	21.692
LM102949 LM102910	73.431	45.242	19.812
LM603049 LM603011	77.788	45.242	19.842
LM603049 LM603012	77.788	45.242	19.842
LM603049 LM603014	79.974	45.242	19.842
25590 25526	85	45.618	25.4
LM503349R LM503310	74.976	45.987	18
18690 18620	79.375	46.038	17.462
359A 354A	85	46.038	21.692
359S 354A	85	46.038	21.692
2984 2924	85	46.038	25.608
369A 362A	88.9	47.625	22.225
M804049 M804010	88.9	47.625	25.4
HM804846 HM804810	95.25	47.625	29.37
386A 382A	96.838	47.625	21.946
528 522	1.6	47.625	36.068
463 453X	4.775	47.625	29.317
467 453X	4.775	47.625	29.317
45282 45220	4.775	47.625	30.958
HM804848 HM804810	95.25	48.412	29.37
HM804849 HM804810	95.25	48.412	29.37
365S 362A	88.9	49.212	22.225
HM807044 HM807010	4.775	49.212	36.512
65390 65320	14.3	49.212	44.45
HH506348 HH506310	14.3	49.212	44.45
28579R 28521	92.075	49.987	25.4
JLM104948 JLM104910	82	50	21.501
365 362A	88.9	50	22.225
366 362A	88.9	50	22.225
JM205149 JM205110	90	50	28
JHM807045 JHM807012	105	50	36
396 394A	110	50	21.996
L305649R L305610	80.962	50.8	18.258
LM104949 LM104911	82.55	50.8	22.225
18200 18337	85.725	50.8	18.263
18790 18724	88.9	50.8	17.462
368 362A	88.9	50.8	22.225
368A 362A	88.9	50.8	22.225
370A 362A	88.9	50.8	22.225
28580R 28521	92.075	50.8	25.4
375 374	93.264	50.8	22.225
3780 3720	93.264	50.8	30.302
3780 3730	93.264	50.8	30.302
33889 33822	95.25	50.8	28.575
385AX 382A	96.838	50.8	21.946
28678 28622	97.63	50.8	24.608
3780 3732	98.425	50.8	30.302
49585 49520	101.6	50.8	31.75
529 522	101.6	50.8	36.068
529X 522	101.6	50.8	36.068
45284 45220	104.775	50.8	30.958
59200 59412	104.775	50.8	36.512

Inch SYBR Tapered Roller Bearing Application:

SYBR Tapered Roller Bearings Pictures:

Our Advantages:
