NTN MU1205TM National - Cylindrical Roller Bearings

A full line of premium oil seals and bearings Premium bearing design matches OEM specifications Precision manufactured using premium steel grades for outstanding durability and performance High radial load capacity makes them suitable for high speed applications

MU1205TM drawing:

• Cup Outside Diameter (In): 2.047 Inch
• Outside Diameter (In): 2.0472 Inch
• Outside Diameter (mm): 52mm
• Type: NS
• Width (In): 0.5906 Inch
• Width (mm): 15mm

Basic Bearing Number

1,205

Bearing Series

1200

Bearing Width

15.0000 mm

Bore Diameter

25.0000 mm

Diameter - Outside

52.0000 mm

Housing Shoulder Diameter (Plain Outer Ring) [Max]

47.00 mm

Housing Shoulder Diameter (Ribbed Outer Ring) [Max]

44.70 mm

Inner Fillet Radius

1.02 mm

Inner Ring and Roller Assembly Over Roller Diameter

44.82 mm

Inner Ring Raceway Outside Diameter

32.17 mm

Inner Ring Rib Outside Diameter

34.32 mm

Inner Ring Type

Double Rib (U)

Outer Corner Radius

1.02 mm

Outer Ring and Roller Assembly Under Roller Diameter

32.20 mm

Outer Ring Raceway Inside Diameter

44.85 mm

Outer Ring Rib Inside Diameter

42.95 mm

Outer Ring Type

Outer Ring With Two Retaining Rings in I.D. (T)

Product Feature Summary

Contoured roller pockets; Fully crowned rollers; Optional full complement; Precision ground ribs; Rollers individually separated; See Features & Benefits for additional info.

Retainer Type

Full Complement (M - No Retainer)

Ring Width Series

Narrow (1)

Rolling Element

Cylindrical

Series Weight

Light (2)

Shaft Shoulder Diameter (Plain Inner Ring) [Min]

30.50 mm

Shaft Shoulder Diameter (Ribbed Inner Ring) [Min]

32.00 mm

Unit of Measure

in
