ASAHI UCP209 Bearing Unit Housing

Our company can provide specific bearing parameter, drawings, one-to-one solutions, and considerate after sales service. For more product information, please consult us at any time .We provide 24-hour service and await your calls respectfully!

Description

Technical

Application

Pictures

The Brief Description of Asahi Bearing Units :

A pillow block bearing is a type of bearing that is housed within a cast-iron mounting bracket that doubles as the outer housing for the bearing. Typically manufactured from a gray cast iron, the pillow block bearing housing has provisions to allow the housing to be bolted down snugly. The inner bearing component of the pillow block bearing is commonly a soft metal material, such as white metal, while the outer housing can be a split or single housing. Primarily designed for low-torque, minimal-load situations.

Standard Asahi Pillow Block Bearing unit : Light, Medium & Heavy Duty Series
• Pillow Blocks
• Flange Units
• Cartridge Units
• Take up Units
• Hanger Bearings Units
• Framed Take-up Units

Stainless Steel Series Asahi Bearing Units :
• Stainless Housing & Inserts
• Recommended for Food & Chemical Industries

Name	Asahi Pillow Block Asahi Bearing
Description	High quality
Material	Chrome steel Gcr15
Delivery	2-3 days
Price	EXW price (factory wholesale price)
Service	24 hours online
Appication	Motor, Machinery, Electric Tools, Sports Apparatus, medical equipment, chemicals, aviation, perfume bottles, sprayers, valves, nail polish, body jewelry, mobile phone panels, toys, etc.
Specialty	1) Very durable 2) High speed running 3) High quality 4) 2 years warranty 5) Good & competitive price

Stock List of ASAHI pillow block bearings :

Model No.	Dimensions mm												Bolt Size	Bearing No.	Housing No.	Weight
Model No.	d	h	a	e	b	s1	s2	g	w	t	B	n	mm	Bearing No.	Housing No.	(kg)
UCP201	12	30.2	127	95	38	13	19	14	62	44.5	31	12.7	M10	UC201	P203	0.69
UCP202	15	30.2	127	95	38	13	19	14	62	44.5	31	12.7	M10	UC202	P203	0.69
UCP203	17	30.2	127	95	38	13	19	14	62	44.5	31	12.7	M10	UC203	P203	0.68
UCP204	20	33.3	127	95	38	13	19	15	71	48	34.1	14.3	M10	UC204	P204	0.66
UCP205	25	36.5	140	105	38	13	19	15	71	48	34.1	14.3	M10	UC205	P205	0.81
UCP206	30	42.9	165	121	48	17	20	17	84	53	38.1	15.9	M14	UC206	P206	1.24
UCP207	35	47.6	167	127	48	17	20	18	93	59.5	42.9	17.5	M14	UC207	P207	1.58
UCP208	40	49.2	184	137	54	17	20	18	100	69	49.2	19	M14	UC208	P208	1.89
UCP209	45	54	190	146	54	17	20	20	106	69	49.2	19	M14	UC209	P209	2.14
UCP210	50	57.2	200	159	60	20	23	21	113	74.5	51.6	19	M16	UC210	P210	2.66
UCP211	55	63.5	219	171	60	20	23	23	125	76	55.6	22.2	M16	UC211	P211	3.31
UCP212	60	69.8	241	184	70	20	23	25	138	89	65.1	25.4	M16	UC212	P212	4.9
UCP213	65	76.2	265	203	70	25	28	27	150	89	65.1	25.4	M20	UC213	P213	5.15
UCP214	70	79.4	266	210	72	25	28	27	156		74.6	30.2	M20	UC214	P214	6.2
UCP215	75	82.6	275	217	74	25	28	28	162		77.8	33.3	M20	UC215	P215	7.16
UCP216	80	88.9	292	232	78	25	28	30	174		82.6	33.3	M20	UC216	P216	8.1
UCP217	85	95.2	310	247	83	25	28	32	185		85.7	34.1	M20	UC217	P217	9.81
UCP218	90	101.6	327	262	88	27	30	33	198		96	39.7	M22	UC218
